Optical System - Color Infinity corrected Optical
system.
Observation - Trinocular head, 45 inclined, interpupillary
distance adjustment range 54-75mm, one eyepiece tube with ±5 diopter adjustment
light splitting ratio: binocular 100%; binocular 0%/trinocular 100%.
Eyepiece - PL10X22mm high eye-point plan eyepiece.
Objective - Long working distance infinity plan fluorescence
objective. LWD 4X/0.13/WD18.52, LWDPH10X/0.30/WD7.11, LWDPH20X/0.45/WD5.91,
LWDPLF40X/0.65/WD1.61. Phase contrast kit with centering telescope and green
filter.
Nosepiece - Quintuple nosepiece revolving on ball
bearings.
Stage and accessories - 160x250mm platform; Mechanical stage,
move range 120x78mm; auxiliary stage 70x180mm; Slide Glass holder; Metal stage
with slot; Terasaki holder; Holder for φ35mm petri dish vessel.
Microscope body - Coaxial focus system, coarse focus distance
25mm, fine focus precision 0.002mm, with degree oftightness adjustment, built-in
90-240V wide voltage transformer.
Reflected fluorescence - U-LH100HG mercury lamp house, center
and focus adjustable. With mirror, center and focus adjustable.
Illumination - Centering objective for mercury lamp. Optical
band pass filter cubes: UV1/B1/G130ND25 attenuation pad. The light-filter system
of main body: 2 excitation light waves, B (blue filter), G (green filter) and O
(transmitted light).
Transmitted - Critical illumination, 6V/30W halogen bulb,
center presetting, brightness adjustable. Iris aperturediaphragm.
Condenser - N.A.0.3 long working distance condenser,
W.D.72mm,.
Filters - LBD color temperature change filter, IF550 contrast
green filter.
Accessories - Fuse 2 no.s, instruction manual.
